Electrolux Dishwasher Error Codes – Complete Guide
This guide lists Electrolux dishwasher error codes with their likely causes and solutions. Use it to diagnose issues and know when to fix yourself or when to contact a technician.
01–24 – Delayed Start Option
- Cause: The delay start option has been set.
- Solution: Cancel the delay function or wait for the cycle to begin when the time reaches zero.
1–199 – Minutes Remaining
- Cause: This is not a fault code, but indicates the number of minutes left in the current programme.
- Solution: Allow the dishwasher to complete its cycle normally.
LOC – Door Locked
- Cause: The dishwasher door is locked for safety.
- Solution: Ensure the door is fully closed; press START/CANCEL to clear.
CL or Cd – Door Open Error
- Cause: Door not fully latched or a faulty door latch/switch.
- Solution: Close the door securely; inspect or replace the latch if necessary.
Hd or HO – Heat Delay / Heater On
- Cause: Dishwasher heating water to the required temperature.
- Solution: Normal operation; wait for the code to disappear.
i10 – Water Fill (No Fill)
- Cause: Not enough water entering the appliance.
- Solution: Turn on water supply, check inlet hose for kinks, clean inlet filters.
i11 – Water Fill / Pressure Issue
- Cause: Incorrect water pressure or filling problem.
- Solution: Verify pressure settings and hoses are free from blockages; check inlet valve.
iF0 / iF1 – Fill Fault / Overfill
- Cause: Detected overfill condition.
- Solution: Check float switch, inlet valve and water supply; drain excess water.
i20 – Did Not Drain Completely
- Cause: Blocked or improperly installed drain hose, clog in filters.
- Solution: Clear hose or filters, ensure correct hose height, reset unit if needed.
i40 – Clogged Filter or Sump
- Cause: Food soils or debris in the filter/sump.
- Solution: Clean the filter and sump area thoroughly.
PF – Power Failure
- Cause: Dishwasher lost electrical power.
- Solution: Press START/CANCEL and restart cycle; check mains power.
Er‑01 – Water Leak Detected
- Cause: Leak detected by sensor under the dishwasher.
- Solution: Switch off power, inspect hoses/pumps/tub for leaks; replace leaking parts.
Er‑02 – Thermistor / Turbidity Sensor Failure
- Cause: Faulty water quality/temperature sensor.
- Solution: Check wiring and replace sensor if necessary.
Er‑03 – Wash Motor Failure
- Cause: Problems with the circulation/wash motor.
- Solution: Inspect wiring, remove obstructions, and replace motor if faulty.
Er‑04 / Er‑05 – Upper Fan / Vent Failure
- Cause: Faulty upper fan or vent motor.
- Solution: Check wiring and replace fan/vent assembly.
Er‑06 – Lower Fan Failure
- Cause: Lower fan malfunction.
- Solution: Inspect wiring; replace fan if needed.
Er‑07 / Er‑11 – Drain Valve Failure
- Cause: Drain valve stuck or broken.
- Solution: Check for blockages and replace the valve if defective.
Er‑08 – User Interface Control Failure
- Cause: Defective control panel.
- Solution: Replace the user interface.
Er‑09 – Communication Failure (UI & Control Board)
- Cause: Wiring issue between the control panel and main board.
- Solution: Check connections; replace faulty board or panel.
Er‑10 – Control Board Relay Failure
- Cause: Relay on the electronic board has failed.
- Solution: Replace the electronic control board.
Er‑12 – Drain Valve Position Error
- Cause: Drain valve activated incorrectly.
- Solution: Check wiring; replace valve or board as needed.
Er‑13 – Electronic Control Board Failure
- Cause: Internal failure of the control board.
- Solution: Replace the main electronic control board.
Note: Some codes vary by model; always refer to your model’s user manual for specific guidance.
